1060 Waverider – Commercial

1060

Waverider

Commercial

Performance meets Excellence

As the largest model in the Gemini Waverider Series, the WR1060 stands as the pinnacle of our RIB range. Renowned for its rugged construction and outstanding capabilities, this high-speed, multi-mission vessel is engineered to deliver unmatched performance in the most demanding maritime environments.

Nicknamed "The Beast", the WR1060 features a proven deep-V hull design that ensures superior sea-keeping, stability, and speed—even in the harshest sea conditions. Its exceptional handling and durability make it the trusted choice for military, law enforcement, commercial, and offshore rescue operations.

The expansive deck layout offers complete configuration flexibility, allowing operators to tailor the vessel to their specific mission requirements. With a robust composite hull, high payload capacity, and extended operational range, the WR1060 is built to go the distance—reliably, safely, and comfortably.

Whether you're tackling offshore rescue, military patrol, or commercial operations—or even pursuing high-performance leisure boating—the WR1060 sets a new standard in the world of Rigid Inflatable Boats.

Standard Features

Vacuum Infused Deep V Hull
Vacuum Infused Deck
Hypalon Tubes (1670Dtex)
2 x Heavy Duty Rub Strakes
Full Length Grab Line
7 x Inflation Valves
7 x Over Pressure Release Valves
Internally Taped Seams
2 x Stainless Steel Bow Eyes
Anchor Rope Bow Protection
Anchor Locker

Aluminium Keel Protection
4 x Transom Knees
Engine Motor Well
Under Deck Cable Track
2 x Below Deck Fuel Compartments (2 x 328lt Fuel Tanks)
2 x Stainless Steel Transom Towing Points
Self-Draining Non-Slip Deck
Double Action (Tube Inflation Air) Pump
1 x Repair kit

Technical Specifications

WR1060
Length (m)	10,60
Tube Material	Hypalon
No of Tube Compartments	7
Estimated Waterline Length (m)	9,55
GRP Length (m)	9,68
GRP Beam (m)	2,42
Internal Beam (m)	1,90
External Beam (m)	3,25
Inflated Tube Pressure (BAR)	0,25
Estimated Draft Motor Up / Down (mm)	530 / 730
Dry Weight Hull, Deck & Tube Approximate (Kg’s)	1400
Max Load on Builders Plate (Kg’s)	1600
Maximum Fuel Capacity (L)	1080
Maximum Transom Power (Hp)	700
Maximum Transom Power (kW)	522
Shaft Length Single Installation Inch / mm	30 / 762
Shaft Length Twin Installation Inch / mm	25 / 635
Max Pax	18
Design Category	B
ISO	6185_4

Gallery

Enquire Now

DISCLAIMER: Whilst every attempt has been made by GEMINI to give accurate information, all data provided by GEMINI is intended for guidelines only. Engine size, weight and propeller selection can affect a boat’s performance and/or regulatory compliance. Regulations pertaining to maximum passengers, payload and permissible engine power and other rules differ from country to country , it is a customer’s own responsibility to comply with their own local regulations at all times. GEMINI reserves the right to amend specifications and technical data or withdraw product without prior notice.
